Stirrers and shakers · Overhead stirrers
JOANLAB overhead stirrer · OS-15/30 series
OS-15S · 10 L · no through shaftOS-30S · 20 L · no through shaftOS-15Pro · 10 L · through shaftOS-30Pro · 20 L · through shaft
Overhead stirrers for 10 and 20 L with brushless motor; the Pro versions let the shaft pass through the head to adjust its height.
- Volumes of 10 and 20 L
- Rated torque of 15 and 30 N·cm
- Maximum viscosity of 8000 and 16,000 mPa·s
- Through shaft on the Pro versions
Configurations, certifications, power supply, accessories and availability are confirmed in the quote.
Specifications
Summary datasheet
| Maximum volume | 10 L (OS-15S and OS-15Pro) and 20 L (OS-30S and OS-30Pro) |
| Speed | 100-1500 rpm on the 10 L units; 50-1200 rpm on the 20 L units |
| Rated torque | 15 N·cm and 30 N·cm |
| Maximum viscosity | 8000 and 16,000 mPa·s |
| Through shaft | No on the S versions; yes on the Pro versions |
| Timer | 1 min to 24 h on the S versions; 0 to 24 h on the Pro versions |
| Chuck | 1-10 mm |
| Power | 50 W and 60 W |
| Power supply | AC 100-240 V with an external 24 V DC / 2.5 A adapter |
| Paddles | Four-blade and three-blade standard; disc, paddle, three-blade and cross types optional |
| Shipping package | 39 × 31 × 16.5 cm and 7.5 kg (OS-15S, OS-30S and OS-15Pro); 39 × 28 × 17 cm and 8.1 kg (OS-30Pro) |
| Availability | Imported to order / to be confirmed |
10 or 20 liters, and the 30 doubles the torque
The 15 states 10 L, 15 N·cm and 8000 mPa·s at 100-1500 rpm; the 30 rises to 20 L, 30 N·cm and 16,000 mPa·s while turning slower (50-1200 rpm): it enters liquids twice as viscous in exchange for speed ceiling.
S or Pro: the base and the paddle
The catalog's note is verbatim: the S has an H-base and its paddle cannot pass through the head; the Pro has a non-slip base and the paddle can. The mixing figures are identical between the two.
